Table Space Layout#
In the broad sense, a Table includes two parts: the main table and TOAST table:
- Main table: stores the relation’s own data, i.e., the narrow sense relation,
relkind='r'
. - TOAST table: corresponds one-to-one with the main table, stores oversized fields,
relkind='t'
.
Each table consists of main body and indexes - two Relations (for main tables, index relations may not exist):
- Main relation: stores tuples.
- Index relation: stores index tuples.
Each relation may have four forks:
main: the relation’s main file, numbered 0
fsm: stores information about free space in the main fork, numbered 1
vm: stores information about visibility in the main fork, numbered 2
init: used for unlogged tables and indexes, a rare special fork, numbered 3
Each fork is stored as one or more files on disk: files larger than 1GB are split into multiple segments of maximum 1GB each.
In summary, a table is not as simple as it appears - it consists of several relations:
- Main table’s main relation (single)
- Main table’s indexes (multiple)
- TOAST table’s main relation (single)
- TOAST table’s index (single)
Each relation may actually contain 1-3 forks: main
(always exists), fsm
, vm
.
Getting Table’s Associated Relations#
Use the following query to list all fork oids:
select
nsp.nspname,
rel.relname,
rel.relnamespace as nspid,
rel.oid as relid,
rel.reltoastrelid as toastid,
toastind.indexrelid as toastindexid,
ind.indexes
from
pg_namespace nsp
join pg_class rel on nsp.oid = rel.relnamespace
, LATERAL ( select array_agg(indexrelid) as indexes from pg_index where indrelid = rel.oid) ind
, LATERAL ( select indexrelid from pg_index where indrelid = rel.reltoastrelid) toastind
where nspname not in ('pg_catalog', 'information_schema') and rel.relkind = 'r';
nspname | relname | nspid | relid | toastid | toastindexid | indexes
---------+------------+---------+---------+---------+--------------+--------------------
public | aoi | 4310872 | 4320271 | 4320274 | 4320276 | {4325606,4325605}
public | poi | 4310872 | 4332324 | 4332327 | 4332329 | {4368886}
Statistical Functions#
PostgreSQL provides a series of functions to determine the space occupied by various parts.
Function | Statistical Scope |
---|---|
pg_total_relation_size(oid) | Entire relation, including table, indexes, TOAST, etc. |
pg_indexes_size(oid) | Space occupied by relation’s index portion |
pg_table_size(oid) | Space occupied by relation excluding indexes |
pg_relation_size(oid) | Get size of a relation’s main file part (main fork) |
pg_relation_size(oid, 'main') | Get relation’s main fork size |
pg_relation_size(oid, 'fsm') | Get relation’s fsm fork size |
pg_relation_size(oid, 'vm') | Get relation’s vm fork size |
pg_relation_size(oid, 'init') | Get relation’s init fork size |
Although physically a table consists of so many files, logically we usually only care about the size of two things: table and indexes. Therefore, the main functions used here are pg_indexes_size
and pg_table_size
, whose sum equals pg_total_relation_size
for regular tables.
The table size portion can typically be calculated as:
pg_table_size(relid)
= pg_relation_size(relid, 'main')
+ pg_relation_size(relid, 'fsm')
+ pg_relation_size(relid, 'vm')
+ pg_total_relation_size(reltoastrelid)
pg_indexes_size(relid)
= (select sum(pg_total_relation_size(indexrelid)) where indrelid = relid)
Note that TOAST tables also have their own indexes, but there is only one, so using pg_total_relation_size(reltoastrelid)
can calculate the overall size of the TOAST table.
Example: Statistics for a Specific Table and Related Relations UDTF#
SELECT
oid,
relname,
relnamespace::RegNamespace::Text as nspname,
relkind as relkind,
reltuples as tuples,
relpages as pages,
pg_total_relation_size(oid) as size
FROM pg_class
WHERE oid = ANY(array(SELECT 16418 as id -- main
UNION ALL SELECT indexrelid FROM pg_index WHERE indrelid = 16418 -- index
UNION ALL SELECT reltoastrelid FROM pg_class WHERE oid = 16418)); -- toast
This can be wrapped as a UDTF: pg_table_size_detail
, for convenient use:
CREATE OR REPLACE FUNCTION pg_table_size_detail(relation RegClass)
RETURNS TABLE(
id oid,
pid oid,
relname name,
nspname text,
relkind "char",
tuples bigint,
pages integer,
size bigint
)
AS $$
BEGIN
RETURN QUERY
SELECT
rel.oid,
relation::oid,
rel.relname,
rel.relnamespace :: RegNamespace :: Text as nspname,
rel.relkind as relkind,
rel.reltuples::bigint as tuples,
rel.relpages as pages,
pg_total_relation_size(oid) as size
FROM pg_class rel
WHERE oid = ANY (array(
SELECT relation as id -- main
UNION ALL SELECT indexrelid FROM pg_index WHERE indrelid = relation -- index
UNION ALL SELECT reltoastrelid FROM pg_class WHERE oid = relation)); -- toast
END;
$$
LANGUAGE PlPgSQL;
SELECT * FROM pg_table_size_detail(16418);
Sample return result:
geo=# select * from pg_table_size_detail(4325625);
id | pid | relname | nspname | relkind | tuples | pages | size
---------+---------+-----------------------+----------+---------+----------+---------+-------------
4325628 | 4325625 | pg_toast_4325625 | pg_toast | t | 154336 | 23012 | 192077824
4419940 | 4325625 | idx_poi_adcode_btree | gaode | i | 62685464 | 172058 | 1409499136
4419941 | 4325625 | idx_poi_cate_id_btree | gaode | i | 62685464 | 172318 | 1411629056
4419942 | 4325625 | idx_poi_lat_btree | gaode | i | 62685464 | 172058 | 1409499136
4419943 | 4325625 | idx_poi_lon_btree | gaode | i | 62685464 | 172058 | 1409499136
4419944 | 4325625 | idx_poi_name_btree | gaode | i | 62685464 | 335624 | 2749431808
4325625 | 4325625 | gaode_poi | gaode | r | 62685464 | 2441923 | 33714962432
4420005 | 4325625 | idx_poi_position_gist | gaode | i | 62685464 | 453374 | 3714039808
4420044 | 4325625 | poi_position_geohash6 | gaode | i | 62685464 | 172058 | 1409499136
Example: Relation Size Details Summary#
select
nsp.nspname,
rel.relname,
rel.relnamespace as nspid,
rel.oid as relid,
rel.reltoastrelid as toastid,
toastind.indexrelid as toastindexid,
pg_total_relation_size(rel.oid) as size,
pg_relation_size(rel.oid) + pg_relation_size(rel.oid,'fsm')
+ pg_relation_size(rel.oid,'vm') as relsize,
pg_indexes_size(rel.oid) as indexsize,
pg_total_relation_size(reltoastrelid) as toastsize,
ind.indexids,
ind.indexnames,
ind.indexsizes
from pg_namespace nsp
join pg_class rel on nsp.oid = rel.relnamespace
,LATERAL ( select indexrelid from pg_index where indrelid = rel.reltoastrelid) toastind
, LATERAL ( select array_agg(indexrelid) as indexids,
array_agg(indexrelid::RegClass) as indexnames,
array_agg(pg_total_relation_size(indexrelid)) as indexsizes
from pg_index where indrelid = rel.oid) ind
where nspname not in ('pg_catalog', 'information_schema') and rel.relkind = 'r';
